Choke Ball Valve

In Line Valve Co. Choke Ball Valves combine a ‘Positive’ ‘Fixed Bean Choke’ with a double block and bleed ball valve which allows for the valve to be used as a shut off valve and a choke.

The valve is designed to be able to isolate pressure from upstream and downstream to allow for the ‘side door’ to be opened and for the choke bean to be changed.

Control Choke Valve, Plug and Cage Choke, External Sleeve Choke, Multistage Choke, Oil and Gas Choke Valve, Severe Service Choke, Severe Service Control Valve, Gas Lift Choke, Anticavitation Valve, Dump Valve, Water Injection Choke, UK, United Kingdom
Control Choke Valve, Plug and Cage Choke, External Sleeve Choke, Multistage Choke, Oil and Gas Choke Valve, Severe Service Choke, Severe Service Control Valve, Gas Lift Choke, Anticavitation Valve, Dump Valve, Water Injection Choke, UK, United Kingdom

Control Choke Valve, Plug and Cage Choke, External Sleeve Choke, Multistage Choke, Oil and Gas Choke Valve, Severe Service Choke, Severe Service Control Valve, Gas Lift Choke, Anticavitation Valve, Dump Valve, Water Injection Choke, UK, United Kingdom

Nominal Size
Maximum Bean Size
End Connections
2 x 2 x 2
25mm, 64/64”
API 2 1/16”, ANSI 2”
3 x 3 x 3
50mm 128/64”
API 3 1/8” ANSI 3”
4 x 4 x 4
75mm,
API 4 1/16”, ANSI 4”
6 x 6 x 6
135 mm
API 7 1/16”, ANSI 6”
6 x 8 x 6
150 mm
API 7 1/16”, ANSI 6”
Features and Benefits
Fast and convenient change of choke beans
‘In-Line’ Positive choke does not require to be mounted in bend in flowline
Range of Forged API and ANSI type body materials in API and ANSI pressure classes and sizes
Gear operated - actuated version available
Options include soft seating, metal to metal and Firesafe seals
Adaptor to take ‘Standard’ Big John Beans
Side entry closed with Hammer Nut to allow for fast and simple change of beans
Bolted construction allows for field maintenance
